Architectural Perforated Aluminum Sheets



Product Overview

Architectural Perforated Aluminum Sheets are a versatile and stylish solution for modern design and functional applications. Made from lightweight, high-quality aluminum, these sheets are durable, corrosion-resistant, and easy to work with. Their perforated designs provide excellent airflow, light filtration, and aesthetic appeal, making them an ideal choice for architects, designers, and builders.

Technical Specifications(1)

Item	Parameters
Material	Aluminum alloy (6063/T6, etc.)
Thickness	Usually 2.0mm – 4.0mm, customizab
Perforation Rate	10% – 50%, adjustable according to requirements
Hole Diameter	3mm – 20mm, various specifications available
Surface Treatment	PVDF, Polyester, Anodizing, powder coating, fluorocarbon paint, etc.
Color	Customizable according to color cards, common colors include silver white, gray, black, gold, etc.
Size	Conventional sizes are 1200mm×2400mm, 1500mm×3000mm, etc., can also be customized as required

Technical Specifications(2)



Specification	Details
Weight	2.5–3.5 kg per square meter (depending on thickness)
Finish Options	Glossy, Matte, Wood Grain, Brushed, and more
Design	Flower Pattern,geometric design,intricate designs,abstract art,text logos, etc.
Perforation Patterns	Circular, square, diamond, hexagonal, and other patterns available.
Fire Resistance	A2 Fire Rating (non-combustible)
Warranty	10–15 years (depending on finish and application)
Applications	all cladding, ceilings, room dividers, decorative screens,facades, partitions, fences, sunshades, interior decoration, etc.
Installation	Wall mounting (screws or adhesive strips)/Easy installation with various mounting options (screws, brackets, frames)/Includes direct fixing, framed systems, or hook-on panels depending on application
Other Services	Customization Services

Finishes and Customization Options:

• Anodized Finish: Provides a sleek, metallic look with added protection against corrosion.
• Powder-Coated Finish: Offers a wide range of color options with a smooth, durable coating.
• Brushed Aluminum: Features a stylish, matte finish for a contemporary appearance.
• Custom Perforations: Tailor the hole sizes, patterns, and open area percentage to your specific design and functional needs.

Gallery



Factory Video

Contact Us

If you’re interested in our Architectural Perforated Aluminum Sheets,feel free to contact us for more information or a free quote!

Factory Machine

Installation Guide

Installing METERNY’s(Architectural Perforated Aluminum Sheets)Aluminum panels is straightforward, and we provide detailed installation instructions to ensure your project is completed efficiently. Here’s a basic outline of the installation process:

1. Prepare the Surface
   Ensure that the surface to which the Architectural Perforated Aluminum Sheets will be attached is clean, flat, and dry. Any surface irregularities should be addressed to ensure proper adhesion and alignment of the panels.
2. Install the Framework
   Use a suitable metal framework to support the Architectural Perforated Aluminum Sheets.The framework should be aligned according to the measurements specified in the design.
3. Panel Attachment
   Architectural Perforated Aluminum Sheets can be installed using clips, screws, or rivets. The method of attachment will depend on the type of panel and the specific requirements of your project. Ensure that all panels are securely fastened to prevent movement.
4. Final Checks
   After installation, conduct a final inspection to ensure that all Architectural Perforated Aluminum Sheets are properly aligned and securely fastened. Clean the panels to remove any installation debris.

Installation Guide(Short Version )

1. Prepare Tools: Electric drill, screwdriver, expansion plugs, etc.
2. Measure and Mark: Accurately measure and mark installation points based on the installation location.
3. Drill and Fix: Use an electric drill to drill holes at the marked points, install expansion plugs, and then fix the panel to the wall with screws.
4. Adjust and Perfect: Ensure the panel is installed flush and adjust for optimal visual effects.

For more detailed instructions or professional installation services, please contact us.

Why Choose Architectural Perforated Aluminum Sheets?

1. Sophisticated Aesthetics: Architectural perforated aluminum sheets bring a modern, sleek look with customizable patterns that add unique style and character to any space.
2. Wide Range of Applications: These sheets are versatile, suitable for facades, sunshades, privacy screens, acoustic panels, and decorative elements, enhancing both residential and commercial spaces.
3. Custom Design Flexibility: Tailor the hole patterns, sheet dimensions, and finishes to meet your project’s specific needs, offering endless design possibilities for both functionality and creativity.
